HPE Aruba Networking CX 4100i 24p 1GbE 20p Class4 POE and 4p Class6 PoE 4p SFP+ Switch

HPE Aruba Networking CX 4100i 24p 1GbE 20p Class4 POE and 4p Class6 PoE 4p SFP+ Switch

  • Brand: HPE
  • Category:
  • SKU: JL818A
  • EAN: 0190017486888 0190017537818 01 ...7537818 0190017537191 0190017537832 0190017537856 0190017537849 0190017537825 0190017537801 0190017537788 0190017537153 0190017537795more
HPE Aruba Networking CX 4100i 24p 1GbE 20p Class4 POE and 4p Class6 PoE 4p SFP+ Switch, Managed, L2, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting, 1U

Trade Prices

Distributor Product SKU Stock Updated Price
Ingram Micro

ARUBA 4100I 24G CL4/6 POE 4SFP+

 268B1L Register free see stock

Related Products

Reasons To Buy

Ruggedized Access Switch Series

The HPE Aruba Networking CX 4100i Switch Series provides IP30 Ethernet connectivity with high speed uplinks, 30W and 60W PoE, to securely extend the enterprise network and support IoT in harsh environments.
Uses the HPE Aruba Networking CX Switch Operating System (AOS-CX) for a simpler, more consistent operator experience with capabilities fit for ruggedized access.
Achieve versatile deployment with fanless 12 port DIN rail mount and 24 port 1U rack mount models with built-in 1/10 GbE uplinks and up to 360W Class 4 and Class 6 PoE.
Fully-managed enterprise class switches deliver Layer 2 capabilities with support for static routing, ACLs, robust QoS, traffic prioritization, and IPv6 support.
Simplifies ownership with no switch software licensing or subscriptions required.

AI-ready performance and power

The HPE Aruba Networking CX 4100i Switch Series is designed with ASICs that deliver very low latency, increased packet buffering, and adaptive power consumption needed to support AI, Wi-Fi 7, and IoT requirements.
Deploy IoT devices and wireless access points in harsh environments with models that support up to 360W IEEE 802.3at Class 4 and IEEE 802.3.bt Class 6 Power over Ethernet.
Built-in wire speed 1/10 GbE uplinks remove bottlenecks at the access layer where devices connect.
Operational in extended temperatures from -40°C to 70°C using HPE Aruba Networking's industrial transceivers.

Simplified Configuration and Management

The CX 4100i series provides flexibility to manage and simplify configurations with HPE Aruba Networking Switch Multi-Edit Software, easy to use built-in web GUI, or industry standard CLI.
HPE Aruba Networking Switch Multi-Edit Software introduces automation that allows for rapid network-wide changes and verifies policy conformance post network updates.
Ready for software-defined networking with REST APIs for fine-grained programmability of network tasks.
Virtual Switching Framework (VSF) allows you to quickly grow your network using high performance stacking.

Smarter Segmentation

The CX 4100i series supports dynamic segmentation that automatically applies and enforces user, device, and application-aware policies on wired and wireless infrastructures.
Automated device profiling, role-based access control, and Layer 7 firewall features deliver enhanced visibility and performance for a better overall experience for both IT and end-users alike.
It reduces time-consuming and error-prone task of adds, moves and changes.

Description

HPE Aruba Networking CX 4100i 24p 1GbE 20p Class4 POE and 4p Class6 PoE 4p SFP+ Switch. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24, Console port: RJ-45/USB Type-C. MAC address table: 8192 entries, Switching capacity: 128 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE.... Power over Ethernet (PoE). Rack mounting, Form factor: 1U

Specifications

Management features
Switch layerL2
Switch typeManaged
Quality of Service (QoS) supportYes
Multicast supportYes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity24
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Installed SFP modules quantity0
Installed SFP+ modules quantity0
SFP+ module slots quantity4
Console portRJ-45/USB Type-C
Network
Networking standardsIEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3x
VLAN supportYes
Spanning tree protocolYes
Port mirroringYes
10G supportYes
IGMP snoopingYes
Data transmission
MAC address table8192 entries
Switching capacity128 Gbit/s
Throughput95 Mpps
Latency (1 Gbps)1.585 µs
Latency (10 Gbps)1.243 µs
Jumbo frames supportYes
Packet buffer memory12.38 MB
Security
AuthenticationMAC-based authentication, Web-based authentication
SSH/SSL supportYes
Security algorithmsSSH, SSH-2
IGMP snoopingYes
Access Control List (ACL)Yes
Authentication typeRADIUS, TACACS+
DHCP featuresDHCP client
Multicast features
Multicast supportYes
Design
Rack mountingYes
StackableNo
Product colourBlack
Form factor1U
Performance
Processor frequency1016 MHz
Memory typeDDR3-SDRAM
Internal memory4096 MB
Flash memory32000 MB
Built-in processorYes
Processor modelARM Cortex-A9
StackableNo
Packet buffer memory12.38 MB
Harmonized System (HS) code85176990
Power
Power supply includedNo
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power sourceAC
Power over Ethernet (PoE)
Power over Ethernet (PoE)Yes
Total Power over Ethernet (PoE) budget240 W
Operational conditions
Operating temperature (T-T)-40 - 60 °C
Operating relative humidity (H-H)5 - 95%
Storage relative humidity (H-H)5 - 95%
Operating altitude0 - 165354.3" (0 - 4200 m)
Non-operating altitude0 - 181102.4" (0 - 4600 m)
Heat dissipation117 BTU/h
Virtual LAN features
VLAN supportYes
Weight & dimensions
Width17.5" (444.5 mm)
Depth12" (304.4 mm)
Height1.73" (44 mm)
Weight14.3 lbs (6.47 kg)
Logistics data
Harmonized System (HS) code85176990
