Tripp Lite AVR550U uninterruptible power supply (UPS) Line-Interactive 0.55 kVA 300 W 8 AC outlet(s)

Tripp Lite AVR550U uninterruptible power supply (UPS) Line-Interactive 0.55 kVA 300 W 8 AC outlet(s)

Tripp Lite AVR550U, Line-Interactive, 0.55 kVA, 300 W, Pure sine, 110 V, 120 V

Trade Prices

Distributor Product SKU Stock Updated Price
ASI TRIPPLITE 550VA UPS ultra-compact line-interactive UPS single-line TEL DSL surge 45877 Register free see stock
BlueStar TRIPP LITE, 550VA UPS LOW PROFILE AVR LINE-INTERACTIVE 8 OUTLETS AVR550U
D&H 550VA 300W UPS w/ AVR AVR550UCN
Ingram Micro 550VA LOW LINE INTERACTIVE 89846C
Synnex AVR Series 120V 550VA 300W Ultra-Compact Line-Interactive UPS with USB port 4008629

Related Products

Description

Tripp Lite AVR550U. UPS topology: Line-Interactive, Output power capacity: 0.55 kVA, Output power: 300 W. AC outlet types: NEMA 5–15R, Power plug: NEMA 5-15P, AC outlets quantity: 8 AC outlet(s). Battery voltage: 12 V, Typical backup time at half load: 9 min, Battery recharge time: 9 h. Form factor: Tower, Product color: Black, Housing material: Acrylonitrile butadiene styrene (ABS). Width: 6.4" (162.6 mm), Depth: 12" (304.8 mm), Height: 4.33" (110 mm)

Specifications

Power
Output power capacity0.55 kVA
Output power300 W
Input operation voltage (min)110 V
Input operation voltage (max)120 V
Output operation voltage (min)110 V
Output operation voltage (max)120 V
Surge energy rating316 J
Maximum current15 A
Output frequency50/60 Hz
Ports & interfaces
Cable length59.1" (1.5 m)
AC outlets quantity8 AC outlet(s)
AC outlet typesNEMA 5–15R
Power plugNEMA 5-15P
USB portYes
USB 2.0 ports quantity1
Performance
UPS topologyLine-Interactive
EMI/RFI noise filteringYes
Surge protectionYes
WaveformPure sine
LED indicatorsYes
Audible alarm(s)Yes
Features
UPS topologyLine-Interactive
Output power capacity0.55 kVA
Country of originChina
Output power300 W
Input operation voltage (min)110 V
Input operation voltage (max)120 V
Output operation voltage (min)110 V
Output operation voltage (max)120 V
Surge energy rating316 J
Maximum current15 A
EMI/RFI noise filteringYes
Surge protectionYes
WaveformPure sine
Output frequency50/60 Hz
Audible alarm(s)Yes
Battery
Battery recharge time9 h
Typical backup time at half load9 min
Cold startYes
Battery voltage12 V
Design
Form factorTower
Country of originChina
Product colourBlack
CertificationUL1778, CSA, NOM, FCC
Cable length59.1" (1.5 m)
LED indicatorsYes
Housing materialAcrylonitrile butadiene styrene (ABS)
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 45 °C
Operating relative humidity (H-H)0 - 90%
Operating altitude0 - 120000" (0 - 3048 m)
Technical details
Output frequency50/60 Hz
Sustainability certificatesRoHS
Compliance certificatesRoHS
Weight & dimensions
Width6.4" (162.6 mm)
Depth12" (304.8 mm)
Height4.33" (110 mm)
Weight13.7 lbs (6.21 kg)
Package width9.3" (236.2 mm)
Package depth14.7" (373.4 mm)
Package height6" (152.4 mm)
Package weight14 lbs (6.35 kg)
Packaging data
Cables includedUSB cable
ManualYes
Package width9.3" (236.2 mm)
Package depth14.7" (373.4 mm)
Package height6" (152.4 mm)
Package weight14 lbs (6.35 kg)
Logistics data
Products per master (outer) case3 pc(s)
Master (outer) case width15.3" (388.6 mm)
Master (outer) case length19.1" (485.1 mm)
Master (outer) case height10.2" (259.1 mm)
Master (outer) case gross weight39 lbs (17.7 kg)
Master (outer) case GTIN (EAN/UPC)10037332211450
Certificates
CertificationUL1778, CSA, NOM, FCC
Packaging content
Cables includedUSB cable
ManualYes
