Tripp Lite N286-40G-LR4 network transceiver module Fiber optic 40000 Mbit/s QSFP+ 1310 nm
- Brand: Tripp Lite
- Category:
- SKU: N286-40G-LR4
- EAN: 0037332248510
Cisco-Compatible QSFP-40G-LR4 QSFP+ Transceiver - 40GBase-LR4, Singlemode LC, 1270-1330 nm, 10 km
Offer details
Description
QSFP+ Transceiver Designed for Connection to Your Cisco Network Switch or Server
This QSFP+ transceiver allows you to connect a singlemode fiber optic cable to a 40 Gbps network router, server or switch. It transmits data up to 10 kilometers (6.2 miles) using a 1270 to 1330 nm wavelength. The zinc housing protects against electromagnetic interference (EMI) and excessive power dissipation.
Functionally Equivalent to Cisco QSFP-40G-LR4 Transceiver Module
The MSA-compliant N286-40G-LR4 functions just like the equivalent Cisco QSFP-40G-LR4 transceiver module and is manufactured to meet or exceed Cisco specifications. You can use this transceiver with any compatible Cisco router, server or switch and receive the same performance as the QSFP-40G-LR4.
Hot-Swappable for Installation Without Network Interruption
This input/output device is fully hot-swappable, so you can install it without a potentially costly 40 Gbps network shutdown or device reboot. Just plug the QSFP+ end of the transceiver into your Cisco network device. The other end has an LC duplex connector to link with singlemode fiber optic cable (sold separately). A push/pull tab connector is easily accessible in high-density data center applications and makes the plug-and-play transceiver easy to install and remove with one hand.
This QSFP+ transceiver allows you to connect a singlemode fiber optic cable to a 40 Gbps network router, server or switch. It transmits data up to 10 kilometers (6.2 miles) using a 1270 to 1330 nm wavelength. The zinc housing protects against electromagnetic interference (EMI) and excessive power dissipation.
Functionally Equivalent to Cisco QSFP-40G-LR4 Transceiver Module
The MSA-compliant N286-40G-LR4 functions just like the equivalent Cisco QSFP-40G-LR4 transceiver module and is manufactured to meet or exceed Cisco specifications. You can use this transceiver with any compatible Cisco router, server or switch and receive the same performance as the QSFP-40G-LR4.
Hot-Swappable for Installation Without Network Interruption
This input/output device is fully hot-swappable, so you can install it without a potentially costly 40 Gbps network shutdown or device reboot. Just plug the QSFP+ end of the transceiver into your Cisco network device. The other end has an LC duplex connector to link with singlemode fiber optic cable (sold separately). A push/pull tab connector is easily accessible in high-density data center applications and makes the plug-and-play transceiver easy to install and remove with one hand.
Specifications
| Performance | |
|---|---|
| SFP transceiver type | Fiber optic |
| Interface type | QSFP+ |
| Maximum data transfer rate | 40000 Mbit/s |
| Fiber optic connector | LC |
| Maximum transfer distance | 393700.8" (10000 m) |
| Wavelength | 1310 nm |
| Single-mode fiber (SMF) supported | Yes |
| Multi-mode fiber (MMF) supported | No |
| SFP transceiver standard | LR4 |
| Country of origin | China |
| Easy to install | Yes |
| Product colour | Silver |
| Hot-swap | Yes |
| Brand compatibility | Cisco |
| Harmonized System (HS) code | 8517.62.0090 |
| Features | |
| Easy to install | Yes |
| Product colour | Silver |
| Hot-swap | Yes |
| Brand compatibility | Cisco |
| Country of origin | China |
| Certificates | |
| Compliance certificates | RoHS |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 5 - 85% |
| Storage relative humidity (H-H) | 5 - 85% |
| Minimum operating temperature | 0 °C |
| Maximum operating temperature | 70 °C |
| Network | |
| SFP transceiver type | Fiber optic |
| Interface type | QSFP+ |
| Maximum data transfer rate | 40000 Mbit/s |
| Fiber optic connector | LC |
| Weight & dimensions | |
| Width | 0.72" (18.3 mm) |
| Depth | 4.77" (121.2 mm) |
| Height | 0.331" (8.4 mm) |
| Weight | 2.12 oz (60 g) |
| Package width | 5.7" (144.8 mm) |
| Package depth | 3.1" (78.7 mm) |
| Package height | 0.701" (17.8 mm) |
| Package weight | 2.12 oz (60 g) |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Package type | Box |
| Packaging data | |
| Package type | Box |
| Package width | 5.7" (144.8 mm) |
| Package depth | 3.1" (78.7 mm) |
| Package height | 0.701" (17.8 mm) |
| Package weight | 2.12 oz (60 g) |
| Technical details | |
| Master (outer) case GTIN (EAN/UPC) | 10037332248517 |
| Compliance certificates | RoHS |
| Logistics data | |
| Quantity per pack | 1 pc(s) |
| Country of origin | China |
| Master (outer) case width | 7.3" (185.4 mm) |
| Master (outer) case length | 5.9" (149.9 mm) |
| Master (outer) case height | 4" (101.6 mm) |
| Master (outer) case gross weight | 24 oz (680 g) |
| Products per master (outer) case | 10 pc(s) |
| Harmonized System (HS) code | 8517.62.0090 |
| Master (outer) case GTIN (EAN/UPC) | 10037332248517 |
