HP Z2 G4 Intel® Core™ i5 i5-9500 16 GB DDR4-SDRAM 256 GB SSD NVIDIA® Quadro® P600 Windows 10 Pro Mini PC Workstation Black

HP Z2 G4 Intel® Core™ i5 i5-9500 16 GB DDR4-SDRAM 256 GB SSD NVIDIA® Quadro® P600 Windows 10 Pro Mini PC Workstation Black

  • Brand: HP
  • Category:
  • SKU: 8JF40UT#ABC
  • EAN: 0194441266917 0194441263626
HP Z2 G4, 3 GHz, Intel® Core™ i5, i5-9500, 16 GB, 256 GB, Windows 10 Pro

Trade Prices

Distributor Product SKU Stock Updated Price
Synnex

SB Z2G4M I5-9500 16GB/256 PC FR

 6426503 Register free see stock

Related Products

Reasons To Buy

Windows 10 Pro 64

Work without compromising on performance or security with Windows 10 Pro, powered by HP’s collaboration and connectivity technology.

Intel® Core™ i5 processor

Experience powerful performance and seamless computing for your everyday tasks and higher performance needs with the Intel® Core™ i5 processor. [4]

NVIDIA® Quadro® P600 graphics card

Get stable, reliable performance on professional workflows that require you to create complex 2D and 3D models with NVIDIA® Quadro® P600 graphics.

Description

HP Z2 G4. Processor frequency: 3 GHz, Processor family: Intel® Core™ i5, Processor model: i5-9500. Internal memory: 16 GB, Internal memory type: DDR4-SDRAM, Memory clock speed: 2666 MHz. Total storage capacity: 256 GB, Storage media: SSD. On-board graphics card model: Intel® UHD Graphics 630, Discrete graphics card model: NVIDIA® Quadro® P600. Operating system installed: Windows 10 Pro, Operating system architecture: 64-bit. Power supply: 200 W. Chassis type: Mini PC. Product type: Workstation

Specifications

Processor
Processor generation9th gen Intel® Core™ i5
Processor frequency3 GHz
Processor familyIntel® Core™ i5
Processor manufacturerIntel
Processor modeli5-9500
Processor cores6
Processor operating modes64-bit
Processor lithography14 nm
Maximum internal memory supported by processor128 GB
Memory types supported by processorDDR4-SDRAM
Memory clock speeds supported by processor2666 MHz
Memory bandwidth supported by processor (max)41.6 GB/s
Tjunction100 °C
Thermal Design Power (TDP)65 W
PCI Express configurations1x8+2x4, 1x16, 2x8
Maximum number of PCI Express lanes16
Processor cache typeSmart Cache
Processor boost frequency4.4 GHz
Processor socketLGA 1151 (Socket H4)
Processor cache9 MB
PCI Express slots version3.0
System bus rate8 GT/s
Processor threads6
Number of processors installed1
Memory
Internal memory16 GB
Internal memory typeDDR4-SDRAM
Maximum internal memory64 GB
Memory layout (slots x size)2 x 8 GB
Memory slots2x SO-DIMM
Memory clock speed2666 MHz
ECCNo
Storage
Total storage capacity256 GB
Optical drive typeNo
Card reader integratedNo
Storage mediaSSD
Number of SSDs installed1
SSD capacity256 GB
SSD interfacePCI Express
Total SSDs capacity256 GB
Graphics
Discrete graphics cardYes
Discrete graphics card modelNVIDIA® Quadro® P600
Discrete graphics memory typeGDDR5
On-board graphics card modelIntel® UHD Graphics 630
Discrete graphics card memory4 GB
On-board graphics card dynamic frequency (max)1100 MHz
On-board graphics card base frequency350 MHz
Maximum on-board graphics card memory64 GB
Number of displays supported (on-board graphics)3
On-board graphics card OpenGL version4.5
On-board graphics card DirectX version12.0
On-board graphics card ID0x3E92
On-board graphics card familyIntel® UHD Graphics
On-board graphics cardYes
Discrete GPU manufacturerNVIDIA
Optical drive
Optical drive typeNo
Network
Ethernet LANYes
Ethernet LAN data rates10,100,1000 Mbit/s
Wi-FiYes
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
BluetoothYes
Bluetooth version5.0
WLAN controller modelIntel Dual Band Wireless-AC 9560
Top Wi-Fi standardWi-Fi 5 (802.11ac)
Antenna type2x2
Ports & interfaces
USB 2.0 ports quantity0
DVI portNo
DisplayPorts quantity2
Microphone inNo
Headphone outputs1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity0
Thunderbolt 3 ports quantity0
Combo headphone/mic portYes
Expansion slots
PCI Express slots version3.0
Design
Product colourBlack
Chassis typeMini PC
Placement supportedHorizontal
Country of originChina
Performance
Product typeWorkstation
Motherboard chipsetIntel C246
Audio chipConexant CX20632-31Z
Market positioningBusiness
Embedded options availableNo
Software
Operating system installedWindows 10 Pro
Operating system architecture64-bit
Processor special features
Thermal Monitoring TechnologiesYes
Intel® OS GuardYes
Intel VT-x with Extended Page Tables (EPT)Yes
Intel TSX-NIYes
Intel Trusted Execution TechnologyYes
Intel Stable Image Platform Program (SIPP)Yes
Intel® Secure KeyYes
Intel® InTru™ 3D TechnologyYes
Intel Clear Video TechnologyYes
Intel® Clear Video HD Technology (Intel® CVT HD)Yes
Intel® AES New Instructions (Intel® AES-NI)Yes
Idle StatesYes
Execute Disable BitYes
Intel Software Guard Extensions (Intel SGX)Yes
Thermal solution specificationPCG 2015C
Supported instruction setsAVX 2.0, SSE4.1, SSE4.2
Scalability1S
Processor package size37.5 x 37.5 mm
Intel Virtualization Technology for Directed I/O (VT-d)Yes
CPU configuration (max)1
Intel Virtualization Technology (VT-x)Yes
Processor ARK ID134895
Intel 64Yes
Enhanced Intel SpeedStep TechnologyYes
Embedded options availableNo
Intel® Turbo Boost Technology2.0
Intel® Hyper Threading Technology (Intel® HT Technology)No
Intel® Quick Sync Video TechnologyYes
Intel® Identity Protection Technology (Intel® IPT)Yes
Brand-specific features
HP segmentBusiness
Power
Power supply200 W
Weight & dimensions
Width8.5" (216 mm)
Depth8.5" (216 mm)
Height2.28" (58 mm)
Weight4.5 lbs (2.04 kg)
Features
Country of originChina
Other features
Processor manufacturerIntel
On-board graphics cardYes
Graphics card interfacePCIe x16
Country of originChina
