HP Z2 Tower G4 Workstation 5DV46UT Intel Xeon E E-2144G 16 GB DDR4-SDRAM 512 GB SSD NVIDIA® Quadro® P2000 Windows 10 Pro for Workstations Black

HP Z2 Tower G4 Workstation 5DV46UT Intel Xeon E E-2144G 16 GB DDR4-SDRAM 512 GB SSD NVIDIA® Quadro® P2000 Windows 10 Pro for Workstations Black

  • Brand: HP
  • Category:
  • SKU: 5DV46UT#ABA
  • EAN: 0193015586185 0193015586246
HP Z2 Tower G4 Workstation 5DV46UT, 3.6 GHz, Intel Xeon E, 16 GB, 512 GB, DVD±RW, Windows 10 Pro for Workstations

Trade Prices

Distributor Product SKU Stock Updated Price
Synnex

SB Z2 G4 TWR XE-2144G 16G/1TB

 6199353 Register free see stock

Related Products

Description

HP Z2 Tower G4 Workstation 5DV46UT. Processor frequency: 3.6 GHz, Processor family: Intel Xeon E, Processor model: E-2144G. Internal memory: 16 GB, Internal memory type: DDR4-SDRAM, Memory clock speed: 2666 MHz. Total storage capacity: 512 GB, Storage media: SSD, Optical drive type: DVD±RW. On-board graphics card model: Intel UHD Graphics P630, Discrete graphics card model: NVIDIA® Quadro® P2000. Operating system installed: Windows 10 Pro for Workstations, Operating system architecture: 64-bit. Chassis type: Tower. Product type: Workstation

Specifications

Processor
Processor frequency3.6 GHz
Processor familyIntel Xeon E
Processor manufacturerIntel
Processor modelE-2144G
Processor cores4
Processor operating modes64-bit
Processor lithography14 nm
Processor codenameCoffee Lake
Bus typeDMI3
Maximum internal memory supported by processor128 GB
Memory types supported by processorDDR4-SDRAM
Memory clock speeds supported by processor2666 MHz
Memory bandwidth supported by processor (max)41.6 GB/s
Tjunction100 °C
Thermal Design Power (TDP)71 W
PCI Express configurations1x16, 2x8, 1x8+2x4
Maximum number of PCI Express lanes16
Processor cache typeL3
Processor boost frequency4.5 GHz
Processor socketLGA 1151 (Socket H4)
Processor cache8 MB
PCI Express slots version3.0
System bus rate8 GT/s
Processor threads8
Number of processors installed1
Memory
Internal memory16 GB
Internal memory typeDDR4-SDRAM
Maximum internal memory128 GB
Memory layout (slots x size)2 x 8 GB
Memory slots4x DIMM
Memory clock speed2666 MHz
ECCNo
Storage
Total storage capacity512 GB
Optical drive typeDVD±RW
Card reader integratedYes
Storage mediaSSD
HDD speed7200 RPM
Number of SSDs installed1
SSD capacity512 GB
Total SSDs capacity512 GB
Graphics
Discrete graphics cardNo
Discrete graphics card modelNVIDIA® Quadro® P2000
Discrete graphics memory typeGDDR5
On-board graphics card modelIntel UHD Graphics P630
Discrete graphics card memory5 GB
On-board graphics card dynamic frequency (max)1150 MHz
On-board graphics card base frequency350 MHz
Maximum on-board graphics card memory128 GB
Number of displays supported (on-board graphics)3
On-board graphics card OpenGL version4.5
On-board graphics card DirectX version12.0
On-board graphics card ID0x3E96
On-board graphics cardYes
Discrete GPU manufacturerNVIDIA
Optical drive
Optical drive typeDVD±RW
Network
Ethernet LANYes
Ethernet LAN data rates10,100,1000 Mbit/s
Wi-FiYes
Wi-Fi standards802.11a, 802.11b, 802.11g
BluetoothYes
Bluetooth version5.0
Top Wi-Fi standardWi-Fi 4 (802.11n)
Antenna type2x2
Ports & interfaces
USB 2.0 ports quantity2
VGA (D-Sub) ports quantity0
DVI portYes
HDMI ports quantity0
DisplayPorts quantity2
Ethernet LAN (RJ-45) ports1
Line-inYes
Line-outYes
Microphone inNo
Headphone outputs0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity6
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity0
Thunderbolt 3 ports quantity0
Combo headphone/mic portYes
Expansion slots
PCI Express slots version3.0
Design
Product colourBlack
Chassis typeTower
Country of originChina
Performance
Product typeWorkstation
Motherboard chipsetIntel C246
Audio chipConexant CX20632-31Z
Embedded options availableNo
Software
Operating system installedWindows 10 Pro for Workstations
Operating system architecture64-bit
Processor special features
Thermal Monitoring TechnologiesYes
Intel® OS GuardYes
Intel VT-x with Extended Page Tables (EPT)Yes
Intel TSX-NIYes
Intel Trusted Execution TechnologyYes
Intel® Secure KeyYes
Intel® InTru™ 3D TechnologyYes
Intel Clear Video TechnologyYes
Intel® Clear Video HD Technology (Intel® CVT HD)Yes
Intel® AES New Instructions (Intel® AES-NI)Yes
Idle StatesYes
Execute Disable BitYes
Intel Software Guard Extensions (Intel SGX)Yes
Intel Enhanced Halt StateYes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)Yes
Supported instruction setsAVX 2.0, SSE4.1, SSE4.2
Scalability1S
Processor package size37.5 x 37.5 mm
Intel Virtualization Technology for Directed I/O (VT-d)Yes
CPU configuration (max)1
Intel Virtualization Technology (VT-x)Yes
Intel TSX-NI version1.00
Intel Secure Key Technology version1.00
Processor ARK ID134862
Intel 64Yes
Enhanced Intel SpeedStep TechnologyYes
Embedded options availableNo
Intel® Turbo Boost Technology2.0
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Quick Sync Video TechnologyYes
Brand-specific features
HP Software providedBuy Office; CyberLink Power2Go; CyberLink PowerDVD; HP Client Security Software; HP PC Hardware Diagnostics UEFI; HP Performance Advisor; HP Remote Graphics Software (RGS) 7.1; PDF Complete - Corporate Edition; HP Sure Recover; HP Manageability Integration Kit Gen2
Weight & dimensions
Width14" (356 mm)
Depth6.65" (169 mm)
Height17.1" (435 mm)
Weight15.4 lbs (7 kg)
Packaging content
Display includedNo
Windows keysYes
Display
Display includedNo
Features
Country of originChina
Other features
Windows keysYes
Processor manufacturerIntel
On-board graphics cardYes
Graphics card interfacePCIe x16
Country of originChina
